BPS C1 D
Value banknotes counting and denomination sorting with two stakers:
BPS C1 is the perfect addition to any cash processing opeearation. It is highly vesatile, easy and convenient to operate, and support unparalleled range of use cases. It can be easy configured for specific applications and offer rigorous security despite low processing costs.

Indispensable aid for day- to-day business
Superior authentication and denomination verification.
Rapid sorting by denomination, series and orientation.
Multicurrency processing for up to ten currencies.
Serial numer reading (opt).
Barcode reading/TITO (opt).
Check scaning (opt).

It is ideal choise for:
Bank branches
Cash center
Casinos
Cash deck
Exchange office
Public trasit authorities
Retailers


BPS C1 D
Technical Data


Counting speed:
Up to 1300 notes/min.

Authenticity detection:
Up to 1050 notes/min

Serial number reading:
Up to 1050 notes/min

Barcode reading:

Up to 1050 notes/min

A total of three speed levels are acurable for manuale setting.

Feed capacity:
500 BN with continous feed.

Capacity of output compartment:
Main compartment 300 BN.
Reject compartment 100 BN.

Power supply:
100-240 VAC, 50/60Hz

Dimensions:
350(W) x 333(D) x 350(H)mm

Weight: 15 Kg

Ports:
Separate customer display
Receipt printer(2 x RS232)
PC data transfer via
USB or LAN





BPS B1 - A value banknotes counting and fitnees sorting with two stakers:

BPS B1
is the perfect addition to any cash processing opeearation. It is highly vesatile, easy and convenient to operate, and support unparalleled range of use cases. It can be easy configured for specific applications and offer rigorous security despite low processing costs.

It is ideal choise for:
Bank branches
Casinos
Exchange office
Public trasit authorities
Retailers

Ergonomically designed:
easy and intuitive to use

User-friendly color LCD
Ergonomic buttons for simple selection of available
operating modes, e.g. "count" and "sort"
Fast machine availability
Easy opening of the entire transport path

BPS B1
Technical Data


Counting speed:
Up to 1000 notes/min.

Authenticity detection:
Up to 1000 notes/min

Fistnees & Serial number reading: Up to 700 notes/min

Barcode reading:

Up to 600 notes/min

A total of three speed levels are acurable for manuale setting.

Feed capacity:
500 BN with continous feed.

Capacity of output compartment:
Main compartment 200 BN.
Reject compartment 50 BN.

Power supply:
100-240 VAC, 50/60Hz

Dimensions:
272(W) x 280(D) x 282(H)mm

Weight: 8.2 Kg

Ports:
External customer display
Receipt printer(2 x RS232)
PC data transfer via
USB or LAN




KOA - 75 - Series one pocket note counter

75 Series models are:
75 D Basic model with size check function
75 MD MG detection and Size check function
75 UD UV detection and Size check function
75 UMD UV, MG detection and Size check function
75 S Series S, UV, MG, IR (2 way size check)
75 V (value)

KOA-75 series are the most trusted and long-
selling banknote counters available on the market today. Designed by professional engi neers, its exceptional durability, accuracy and user-friendly operation makes a reliable banknote counter. We have three different models in this series that are able to satisfy your market needs. We proudly stand by the KOA-75 series, because it is the most trusted and long sellin banknote counters available on the market .

KOA - 75
Technical Data

Hopper capacity: 500 notes

Stacker capacity: 100 notes

Counting Speed:
600/120/1500 notes b/min.

Note size: 50 x 90 / 100 x 185
( in mm)

Dimensions in mm:
280 W - 230 D -255 H

Weight: 6 kg

Power source: AC100-220V. 50/60 Hz

Density setting:
Adjustiable 5 levels

External display,RS-232C I/FCable, USB I/F Cabel

Batching: Variable




KOA - 35 One pocket note counter

35 Series models are:
37 D Basic model with size check function
35 UVD detection and Size check function

The KOA - 35 is an extreme compact machine that is also exeptionally cost saving for banknote processing work.The key quality of the 35 series is its durabulity

The KOA -35
can hold up just as well as our heavy duty machines assuring for a long-life expectancy .

The KOA 35
has neem commended for its accuracy ,Today worldwide, it is the preferred low-end banknote procesing machine.


KOA - 35
Technical Data

Hopper capacity: 500 notes

Stacker capacity: 200 notes

Counting Speed: 600/120/1500 notes b/min
.

Note size: 50 x 850 /110 x 185
 (in mm)

Dimensionsin mm:
280 W - 246 D -255 H

Weight: 6 kg

Power source: AC100-220V. 50/60 Hz

External display,RS-232C I/FCable, USB I/F
Cabel

Density setting:
Adjustiable 5 levels

Batching: Variable



NUMENMATIC SX-07C

High Top Quality Mix Currency Value Counter

Homologated by European Central Bank
Accurated CIS image recognation technology Detecting fake bills by UV,MG, MT & 2 CIS sensors
Sort out different denomination bill
2 CIS configure can read the bill's serial number Report of the counted bills
Simple operation of the soft updated
Heavy duty performance
Attractive Design
Mix Value Currency Counting (ALL, EUR, USD  etc).


Technical Data:

Hopper Capacity: 500 notes
Stacker Capacity: 200 notes
Counting Speed: 800
/1000/1200 n/min

Note Size:                             Min 110x60mm                         Max 185x90mm

Note Thickness:                   0.08 - 0.12mm mm

Dimensions:                             H 240 x W 260 x L 230 mm
Weight: 5,5 Kg
Power Source : AC 110 -220 V 50/60 Hz
Display: Multi-line LCD Graphic
Feed System: 12 Rollers Fricction System
Batching: Variable
Interface:PC interface RS-232 USB: 2.0/3.0 interface




BJ-05

Features
1. UV, MG, MT detecting function
2. Half, chain detecting function
3. Batch presetting, add counting
4. Alarm stop with error message code
5. Self-testing when starting

Technical Data

Counting Speed: 850notes per min
Countable Banknote Size: 115x50mm~167x80mm
Countable Banknote Thickness: 0.06~0.15mm
Counting Display: 3 digits LED
Batch Display: 3 digits LED
Hopper Capacity: 200pcs
Stacker Capacity: 130pcs
Power Source: AC220V 50Hz / AC110V 60Hz
Power Consumption: 60W
Optional Interface: 4 digits LED external display
Unit Dimension: 280(L)x225(W)x140(H)mm
Packing Dimension: 297(L)x340(W)x192(H)mm
N. Weight/G. Weight: 4.00kg / 4.50kg



BNCC – Compact Portable Banknote Counter

Available in 4 versions:
model „A“ - with uv – control
model “B” - with uv and width control
model “C” - with uv, mg and width control
model “D” - with uv, mg, ir and width control

Features:
selection of requested control of security mark
control of half notes and double notes
correct counting of sticking notes
batch control

Technical Data

usable for banknotes within the ranges: length 100 – 175 mm,
width 50 – 110 mm
display range for counting: 1 to 999
- preset number range: 1 to 999
net weight: 2,1 kgs
- power consumed: 25 W
sizes: 220 x 85 x 125 mm
relative humidity: 40 to 90%
environment humidity: 0 to 40 degrees Celsius
noise: 60 db
counting speed: 800 banknotes per min.
-banknote capacity: approx. 130 banknotes
power supply: 12V DC with adaptor 100 - 220V, 2,5A, 50/60 Hz
